PRODUCT FEATURES  Electrical interface compliant to DSFP Module Specification Rev. 1.0  Maximum link length of 70m on OM3 MMF and 100m on OM4 MMF  Hot-pluggable DSFP form factor  Power consumption less than 2.2W  RoHS compliant and lead-free  Support Digital Diagnostic Monitor interface  +3.3V Single power supply  Case operating temperature Commercial: 0°C to +70°C

PRODUCT FEATURES  Supports 103.1Gb/s aggregate bit rate  4x25Gb/s electrical interface  4X25Gb/s CWDM transmitter and PIN/TIA receiver  Maximum link length of 2km on Single Mode Fiber (SMF)  Hot-pluggable QSFP28 from factor  Single 3.3V power supply  Integrated 4-channel CWDM mux/demux for duplex LC operation  Duplex LC receptacles  Maximum power dissipation < 3.5W  RoHS-6 compliant and lead-free  I2C management interface  Case operating temperature Commercial: 0°C to +70°C

PRODUCT FEATURES  Supports 103.1Gb/s aggregate bit rate  4x25Gb/s retimed electrical interface  4X25Gb/s DFB-based LAN-WDM transmitter and PIN/TIA receiver  Maximum link length of 10km on Single Mode Fiber (SMF)  Hot-pluggable QSFP28 footprint  Duplex LC receptacles  Single 3.3V power supply  Maximum power dissipation < 4.5W  RoHS-6 compliant and lead-free  I2C management interface  Case operating temperature Commercial: 0°C to +70°C

PRODUCT FEATURES  Supports 103.1Gb/s aggregate bit rate  4x25Gb/s electrical interface  Maximum link length of 100m on OM4 Multimode Fiber (MMF)  Hot-pluggable QSFP28 footprint  MDC recepatcles interface  Maximum power dissipation<2.5W  RoHS-6 compliant and lead-free  Support Digital Diagnostic Monitor interface  Commercial operating case temperature range:0℃ to 70℃
