Type

Parameters

Unit

Parameters

Channel spacing

GHZ

100

200

Wavelength range

C,L,or C+L band

Channel centers

nm

ITU

Add/Drop insertion loss (single-l)

ch

≤1.1

Add/Drop insertion loss (dual-l)

dB

≤1.8

Express insertion loss (single-l)

nm

≤0.9

Express insertion loss (dual-l)

≤1.4

Channel passband

nm

≥+/-12.5

≥+/-33

Passband ripple

dB

≤0.5

Drop isolation

 Adjacent channel

dB

≥30

      Non-adjacent channel

≥50

Express isolation

≥25

Directivity

dB

≥50

Return loss

dB

≥45

PDL

dB

≤0.15

PMD

ps

≤0.1

Wavelength thermal stability

nm℃

≤0.003

Insertion loss thermal stability

dB/℃

≤0.005

Operating Temperature

℃

-5~ +70

Storage temperature

-40+~85

Dimension

mm

100×80×10

141X115X18

Customer Design

Note: The above specification is without connector.

Type

Channel number

Pigtail Type

Length

Connector

PackageSize

Single Channel

Dual channel

Etc

0:250um

1:900um

2:2mm 3:3mm

4:others

0.5:0.5m

1:1m

3:Others

FP:FC/PC,FC:FC/APC

SP:SC/PC,SA:SC/APC

LP:LC/PC,LA:LC/APC

OO :None X：Others

1:100×80×10mm

2:141×115×18mm
