Type

Parameters

Unit

Parameters

Wavelength range

nm

C-or L-band ITU channels 186.6 to 196.1THz

Channel centers

nm

ITU

Channel

ch

4

8

4

8

Insertion Loss

dB

2.0

3.0

2.0

3.0

Channel space

nm

20

Channel passband

nm

≥+/-12.5

≥+/-33

Passband ripple

dB

≤0.5

Isolation

 Adjacent channel

dB

≥30

 Non-adjacent channel

≥50

Directivity

dB

≥50

Return loss

dB

≥45

PDL

dB

≤0.15

PMD

ps

≤0.1

Wavelength thermal stability

nm℃

≤0.003

Insertion loss thermal stability

dB/℃

≤0.005

Operating Temperature

℃

-5~ +70

Storage temperature

-40+~85

Dimension

mm

100×80×10

141X115X18

Customer Design

Note: The above specification is without connector.

Type

Channel number

Code Type

Pigtail Type

Length

Connector

PackageSize

4Channel

8 channel

Etc

Demux

Mux

0:250um

1:900um

2:2mm 3:3mm

4:others

0.5:0.5m

1:1m

3:Others

FP:FC/PC,FC:FC/APC

SP:SC/PC,SA:SC/APC

LP:LC/PC,LA:LC/APC

OO :None X：Others

1:100×80×10mm

2:141×115×18mm
