PRODUCT FEATURES Up to 1.25Gb/s data links 1550nm DFB laser/1310nm FP laser transmitter and PIN/TIA receiver Maximum link length of 20km on 9/125um SMF Hot-pluggable SFP footprint Low power dissipation BIDI SC/UPC type pluggable optical interface Metal enclosure, for lower EMI Compatible with RoHS Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C

PRODUCT FEATURES Up to 1.25Gbps Data Links 1550nm FP laser/1310nm FP laser transmitter and PIN/TIA receiver Maximum link length of 3km on 9/125um SMF Hot-pluggable SFP footprint LC receptacles Low power dissipation RoHS compliant and lead-free Support Digital Diagnostic Monitor interface Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C Industrial: -40°C to +85°C

PRODUCT FEATURES Up to 1.25Gbps Data Links 1550nm/1490nm DFB laser transmitter and APD/TIA receiver Maximum link length of 120km on 9/125um SMF Hot-pluggable SFP footprint LC receptacles Low power dissipation RoHS compliant and lead-free Support Digital Diagnostic Monitor interface Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C Industrial: -40°C to +85°C

PRODUCT FEATURES Up to 1.25Gbps Data Links 1550nm(1490nm) DFB laser transmitter and PIN/TIA receiver Maximum link length of 80km on 9/125um SMF Hot-pluggable SFP footprint LC receptacles Low power dissipation RoHS compliant and lead-free Support Digital Diagnostic Monitor interface Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C Industrial: -40°C to +85°C

PRODUCT FEATURES Up to 1.25Gbps Data Links 1550nm(1490nm) DFB laser transmitter and PIN/TIA receiver Maximum link length of 60km on 9/125um SMF Hot-pluggable SFP footprint LC receptacles Low power dissipation RoHS compliant and lead-free Support Digital Diagnostic Monitor interface Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C Industrial: -40°C to +85°C

PRODUCT FEATURES Up to 1.25Gbps Data Links 1550nm DFB laser/1310nm FP laser transmitter and PIN/TIA receiver Maximum link length of 20km on 9/125um SMF Hot-pluggable SFP footprint LC receptacles Low power dissipation RoHS compliant and lead-free Support Digital Diagnostic Monitor interface Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C Industrial: -40°C to +85°C

PRODUCT FEATURES Up to 1.25Gbps Data Links 1550nm/1310nm DFB laser transmitter and PIN/TIA receiver Maximum link length of 40km on 9/125um SMF Hot-pluggable SFP footprint LC receptacles Low power dissipation RoHS compliant and lead-free Support Digital Diagnostic Monitor interface Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C Industrial: -40°C to +85°C

PRODUCT FEATURES Up to 1.25Gbps Data Links 1490nm DFB laser/1310nm FP laser transmitter and PIN/TIA receiver Maximum link length of 20km on 9/125um SMF Hot-pluggable SFP footprint LC receptacles Low power dissipation RoHS compliant and lead-free Support Digital Diagnostic Monitor interface Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C Industrial: -40°C to +85°C

PRODUCT FEATURES Up to 1.25Gbps Data Links 1490nm/1310nm DFB laser transmitter and PIN/TIA receiver Maximum link length of 40km on 9/125um SMF Hot-pluggable SFP footprint LC receptacles Low power dissipation RoHS compliant and lead-free Support Digital Diagnostic Monitor interface Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C Industrial: -40°C to +85°C

PRODUCT FEATURES UP to 1.25Gbps data links The DFB laser transmitter and PIN/TIA receiver Up to 120km on 9/125µm SMF Hot-pluggable SFP footprint Duplex LC/UPC type pluggable optical interface Low power dissipation Metal enclosure, for lower EMI RoHS compliant and lead-free Support Digital Diagnostic Monitor interface Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C Extended: -20°C to +85°C

PRODUCT FEATURES Up to 1.25Gb/s data links The DFB laser transmitter and PIN/TIA receiver Up to 90km on 9/125µm SMF Hot-pluggable SFP footprint Duplex LC/UPC type pluggable optical interface Low power dissipation Metal enclosure, for lower EMI RoHS compliant and lead-free Support Digital Diagnostic Monitor interface Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C Extended: -20°C to +85°C Industrial: -40°C to +85°C

PRODUCT FEATURES Up to 1.25Gb/s data links The DFB laser transmitter and PIN/TIA receiver Up to 80km on 9/125µm SMF Hot-pluggable SFP footprint Duplex LC/UPC type pluggable optical interface Low power dissipation Metal enclosure, for lower EMI RoHS compliant and lead-free Support Digital Diagnostic Monitor interface Single +3.3V power supply Compliant with SFF-8472 Case operating temperature Commercial: 0°C to +70°C Extended: -20°C to +85°C Industrial: -40°C to +85°C
