Specifications
|
type |
|
1x2 |
1x4 |
1x6 |
1x8 |
1x12 |
1x16 |
1x24 |
1x32 |
1x64 |
1x128 |
|
|
Operating wavelength |
nm |
1260～1650 |
||||||||||
|
IL （max） |
dB |
3.9 |
7.0 |
9.0 |
10.5 |
12.0 |
13.4 |
15.4 |
16.7 |
20.1 |
23.7 |
|
|
homogeneity（max） |
dB |
0.7 |
0.7 |
0.7 |
0.8 |
0.8 |
1.0 |
1.0 |
1.2 |
1.6 |
2.0 |
|
|
PDL（max） |
dB |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.5 |
0.5 |
|
|
directivity（min） |
dB |
55 |
||||||||||
|
working/storage temperature |
ºC |
-40~85 |
||||||||||
|
Fiber type |
|
G657A1 |
||||||||||
|
Fiber length |
|
Customer design |
||||||||||
|
connector |
|
Customer design |
||||||||||
|
package |
mm |
4*7*65 |
4*12*60 |
6*20*80 |
6*40*100 |
6*60*120 |
||||||
Ordering Information
|
Mode |
Grade |
wavelength |
Package Spec. |
Coupling Ratio |
Fiber type |
Length |
Connector |
|
S: Single Window D: Dule Window T: Three Window |
P: Grade P
A: Grade A
|
13:1310nm 15:1550nm 13/15: 1310/1550nm 13/15: 1310/ 1550nm X:others
|
1: 4*7*65 2: 4*12*60 3: 6*20*80 4: 6*40*100 5: 6*60*120 X: Others
|
1x2 1x4 1x6 1x8 1x12 1x24 1x32 1x64 1x128
|
9: 9/125
X: Others |
0.5:0.5m 10:1.0m 15:1.5m X: Others |
OO:None FA:FC/APC FC:FC/UPC SA:SC/APC SC:SC/UPC ST:ST/UPC LC:LC/UPC XX:Others |
