Operating wavelength(nm)

1262-1670

1X2 or 2X2

Coupling Ratio

Insertion Loss(dB)@1310&1550nm

P

A

50/50

3.6

3.8

40/60

4.7/2.7

4.9/2.9

30/70

6.0/1.9

6.3/2.1

20/80

7.9/1.3

8.4/1.4

10/90

9.2~11.2/0.75

8.8~11.4/0.8

5/95

12.05~14.15/0.4

11.6~14.6/0.5

3/97

≤14.10~16.50/0.35

≤13.60~17.05/0.45

2/98

≤15.60~18.55/0.3

≤15.00~19.20/0.4

1/99

≤18.45~21.70/0.25

≤17.80~22.40/0.35

PDL(dB)

≤0.20

Directivity(dB)

≥55

Operation temperature(℃)

-40~+85

Store temperature(℃)

-40~+85

Dimension(mm)

Φ3.0mm×45mm钢管（250um ），Φ3.0mm×54mm（0.9mmloose tube），

90mm××20mm×10mmABS（0.9mm/2mm/3mm loose tube）

X

Port No.

Operating wavelength

Coupling Ratio

TubeType

Steel tube

Fiber length

Connector

Grade

1X2

1310& 1550

1/99

25:250um

3.0X45

0.5m±2cm

FC/PC,FC/APC

P

2/98

90:90um

3.0X54

1.0m±2cm

SC/PC,SC/APC

A

2X2

N:Non-latching

90X20X10MM

1.5m±2cm

LC/PC,LC/APC

X: Others

X:Others

X:Others

X:Others

X:Others

OO:None,X:Others
